The Sunreef 90 ULTIMATE is a very light carbon, high-performance oriented superyacht which light displacement is only 55 T. Her sleek, marine hulls with reversed bow will allow her to enjoy 20+ knots speeds on sails even in light breeze with a safety and stability of a catamaran. A Compact and minimalist superstructure will reduce air resistance. Also the abundance of green energies on board such as solar panels, wind and hydro generators will be of a great support for the generator and will allow silent running at anchor.
For the first time, the flybridge will not be a typical leisure area but strictly dedicated to sails maneuvering and entirely covered by solar panels with a total area of 54m2 generating 8kW of power which allows for transparent ceilings in the saloon and master cabin. All supported on a honey-comb shaped carbon fiber super structure which becomes the main feature of the interior design. Two helm stations guarantee the skipper easy sailing and great panoramic views. Guests will certainly enjoy the thrill of adventure due to high speeds and the yachts' impressive size.
The entire superstructure will be made of carbon fiber and glass panels. It will ensure increased illumination thanks to light coming not only through large side windows but also directly from the ceiling. It will house internal saloon with galley in the central part and the master cabin in the front section on the right. It will have a stunning, uncovered view over the sea through the vast glass wall and sliding doors giving access to the private outdoor area protected by two side walls of the superstructure. The private terrace outside will feature an owner's spa pool, bar and lounge. Master bathroom will be located down in the port side hull. Left front side of the superstructure will be dedicated to the navigation station.
The port side hull will house one double guest cabin with en-suite bathroom and storage and one crew cabin in the aft. The starboard hull will comprise two double guest cabins with en-suite bathrooms and a service room with storage directly connected with the galley up on the main deck.
The 20m2 cockpit features a sofa, sun pads and a tender garage on the aft.
Fully customized interior design will allow the clients an unlimited range of finish possibilities with the Sunreef's designer's expertise and advice.
This new concept clearly shows that Sunreef Yachts is a true trendsetter in the luxury catamaran design.
Key points:
Light carbon structure 55T
High-performance yacht
- Sleek, marine hulls with a reversed bow
- Hydro generators in the hulls
- Compact and minimalist superstructure
- Flybridge covered with solar panels: total surface area 54m2/total power 8 kW /
- Glass panels on the hulls and superstructure
- Two external helm stations and one navigation station inside
- Comfortable cockpit with sofa and sun pads and a purpose-build dinghy box
- Custom interior design
- Owner suite on the main deck in the front section with private exterior terrace (spa pool, bar and lounge)
- Improved illumination thanks to light coming from the ceiling through glass modules
Specification:
Construction: carbon fibre
LOA: 27.5m / 90ft
BOA: 11m / 36ft
Draft: 2.1m / 6.8ft
Displacement (lightship): 55 T
Sails upwind: 410m² / 4413ft2
Sails downwind: 590m² /6350ft2
Engines: 2 x 240 HP
Cruising speed on motors: 12 knots
Max. speed on sails: 20 + knots
Range on motors: 1500 nautical miles
Water tanks: 2 x 780 L / 2 x 206 US GAL
Fuel tanks: 2 x 2500 L / 2 x 660 US GAL
Total living space: 140m2/ 1506ft2
Total power from solar panels : 8kW
Guests: 8 in one master suite and 3 guest cabins
Crew: 2
Design: Sunreef Yachts
